Sensing Technology:
- MEMS Thermal-D® Technology: Direct mass flow measurement without temperature/pressure compensation, ensuring high accuracy in low-flow applications .
Design Advantages:
- Nano-Coated Sensor Surface: Resistant to oil, water, and fouling, enhancing long-term reliability .
- Wide Dynamic Range: 100:1 turndown ratio for precise measurement across varying flow rates .
Flexible Configuration:
- User-Configurable Parameters: Flow units (slpm/sccm), response time, and output scaling via front-panel buttons or digital interface .
- Multi-Gas Support: Factory-calibrated for CO₂ (B suffix); supports custom gas calibration (e.g., N₂, O₂) 18.

Dimension	Value (Approx.)
Body Length	162 mm (Control Unit) + 205 mm (Display Unit) 18
Body Diameter	38 mm
Weight	2.05 kg (with 1/2" NPT connector) 18
Mounting Orientation	Any (Recommended: Horizontal for optimal stability)

Parameter	Details
Flow Range	0–800 slpm (Full-scale flow indicated by "800" in model)
Accuracy	±1.5% of Reading + 0.2% of Full Scale 18
Repeatability	±0.25% FS
Response Time	10 ms (Default, adjustable up to 1000 ms via software)
Pressure Rating	2 MPa (290 psi) Maximum Operating Pressure 18
Pressure Loss	≤200 Pa at full flow (Estimated for 19mm internal diameter) 18
Operating Temperature	-10°C to +55°C (-14°F to +131°F)
Storage Temperature	-20°C to +65°C (-4°F to +149°F)
Output Signal	- Analog: 4–20mA DC (Linear, "A" suffix) - Digital: RS485 (Modbus RTU, "B" suffix) - Pulse: PULSE output (inferred from "D" suffix) 18
Power Supply	12–24VDC (Typical: 24VDC, ≤50mA)
Connection Type	- N: 1/2" NPT Threaded Port (Standard) 18
Calibration Gas	B: Carbon Dioxide (CO₂, 20°C, 101.325 kPa) 18
Material	- Wetted Parts: 304 Stainless Steel (Corrosion-Resistant) - Housing: Anodized Aluminum
Electrical Interface	5-Pin Mini-DIN Connector (Standard)
Certifications	CE, RoHS Compliant; Optional Explosion-Proof Certifications (Upon Request)
