Unipolar magnetic operation (triggers with south pole of magnet, resets with removal).
Wide operating voltage range for flexible system integration.
High-temperature tolerance suitable for harsh industrial environments.
Fast response time enables high-speed sensing applications.
Compact, industry-standard TO-92 package for easy mounting and replacement.
Built-in reverse voltage protection and ESD resistance for enhanced durability.
Low power consumption for battery-powered or energy-efficient devices.

Applications:

Position sensing (e.g., limit switches, door/window position detectors, gear tooth counting).
Proximity detection (e.g., object presence/absence in industrial automation, consumer electronics).
Speed sensing (e.g., motor RPM measurement, fan speed monitoring, wheel speed detection).
Automotive systems (e.g., ignition timing, transmission position sensing, seatbelt latch detection).
Industrial automation (e.g., conveyor belt position control, valve position feedback).
Consumer electronics (e.g., laptop lid open/close detection, appliance door interlocks).
Robotics (e.g., joint position sensing, end-effector proximity detection).

Operating Voltage Range	4.5 VDC to 24 VDC
Supply Current	6 mA (typical) at 5 VDC; 8 mA (max)
Output Type	Open-collector NPN (sinking)
Output Current Capacity	20 mA (max) continuous
Operating Temperature Range	-40 °C to +150 °C
Storage Temperature Range	-40 °C to +150 °C
Magnetic Operate Point (BOP)	20 Gauss (min) to 70 Gauss (max)
Magnetic Release Point (BRP)	-70 Gauss (min) to -20 Gauss (max)
Hysteresis (BOP - BRP)	≥ 15 Gauss
Response Time	1 μs (typical)
Package Type	TO-92, TO-92S (standard through-hole)
